Liquid Oxygen Plants

Capacity: 20 M3/Hour to 1000 m3/Hour

Output: 20 LITRES/hr to 5000 LITRES/hr (with liquid production LOX and LIN)

Purity: 99.7%

Applications: Medical and Industrial Uses, Pharmaceuticals, Metal Manufacturing, Oil and gas Refinery, Glass and Mining Industry.

Share On:

Description

We are trusted manufacturer and exporter of liquid oxygen plants with precision designing, ASME/CE quality materials and cryogenic low pressure technology. Moreover, our company has acquired the technology, knowhow and designing from internationally reputed Brand ING. L. & A. BOSCHI, ITALY . Our liquid oxygen plants are installed all over the globe and are performing with high efficiency.

Range – 20 LITRES/hr to 3000 LITRES/hr (with liquid production LOX and LIN) (For 100% liquid production for filling liquid tanks) - For production of liquid oxygen /nitrogen for filling in tanks : With leak-proof stainless steel column and skid mounted version for high purity medical and industrial grade oxygen.

Liquid Oxygen Uses/Applications

Medical and Healthcare, Pharmaceuticals
Aerospace Industry
Steel & Metal Manufacturing
Oil and Gas Industry
Laboratory Applications
Glass and Ceramics applications

Production Process of LOX

Air is sucked by a multi stage air compressor and air passes through the following process:

Step 1	Compression of Air This is accomplished by the multistage highly advanced air compressor.
Step 2	Purification of Air This is fulfilled by the Process Skid.
Step 3	Cooling & Liquification of Air This is finished by a highly advanced expansion engine and also by a refrigeration unit (for 100% liquid output).
Step 4	Air Separation (Rectification) This is done by the special 'BOSCHI' type AIR SEPARATION UNIT comprising of upper & lower column and special exchangers. The separation of air is accomplished by the CRYOGENIC PROCESS. The final product from a liquid Oxygen/Nitrogen goes to the storage tank.

Specification

Capacity : 50 to 1,000 m3/hour
Output : 50 to 1000 Liter/Day (Liquid Nitrogen Optional)
Purity : OXYGEN - 99.7% & NITROGEN - 99.999%
Pressure : 2 - 4 Bar

Key Features of UBTL Series LOX Plants

100% stainless steel column as per ASME standards.
Low Power Consumption. No downtime as liquid oxygen stored in Tank.
Low pressure Rotary air compressor by ATLAS COPCO which are the best in the world.
New Technology with 100% stainless steel vacuum insulated condenser
New Design 100% stainless steel head and cold parts of the cryogenic expander.
New Technology liquid pump with 100% super insulated stainless steel cold end.
High purity output upto 99.7%.

Model & Capacity Table of Liquid Oxygen Plants

Production	UBTL-50	UBTL-100	UBTL-200	UBTL-300	UBTL-400	UBTL-500	UBTL-1000
Liquid Oxygen Output (liters per hour)	60	120	235	350	470	590	1172
Purity Oxygen (%)	99.799.7	99.7	99.7	99.7	99.7	99.7	99.7
Liquid Nitrogen Output (liters per hour)	73	144	290	435	578	700	1440
Purity Nitrogen (%)	99% to 99.999% or ppm	99% to 99.999% or ppm	99% to 99.999% or ppm	99% to 99.999% or ppm	99% to 99.999% or ppm	99% to 99.999% or ppm	99% to 99.999% or ppm
